Japanese English Simplified Chinese Remarks/Explanations; Instruction Manual: This describes the cautions upon use, names of parts, charging method, how to install the USB driver, specifications, and other information of the BT-1000/1500 Series. MB3-H2D3-DVD, Marking Builder 3 Version 3 (2D), MD-X series, KEYENCE, UK T0261765 To use all available functions on this website, JavaScript must be enabled in your browser.

Keyence Marking Builder 3 Manual Pdf

Model		MD-X1020
Type		Marking unit (controller + head) 13W Wide area
2D code reader add-in (sold separately)		MD-XAD1/MD-XAD1A
Console (sold separately)		MC-P1
Marking method		XYZ 3-Axis simultaneous scanning method
Marking laser	Type	YVO₄ laser, Class 4 Laser Product (IEC60825-1, JIS C6802, FDA [CDRH] part 1040.10)^*1
	Wavelength	1,064 nm
	Output	13 W
Q-switch frequency		CW (continuous wave), 1 to 400 kHz
Guide laser/Working distance pointer		Semiconductor laser, wavelength: 655 nm, output: 1.0 mW, Class 2 Laser Product (IEC60825-1, JIS C6802, FDA [CDRH] part 1040.10)^*1
Marking area		330 x 330 x 42 mm
Standard working distance (±variable width)		300 mm (±21 mm)
Marking resolution		5 µm
Scan speed		Max. 8,000 mm/s
Character type	Font	KEYENCE original font (numbers, letters, katakana, hiragana, kanji), user font, TrueType font, OpenType font^*2
	Barcode	CODE39, ITF, 2of5, NW7 (CODABAR), JAN, CODE128, EAN, UPC-A, UPC-E
	2D code	QR code, micro QR code, DataMatrix (ECC200/GS1 DataMatrix)
	GS1 DataBar	GS1 DataBar/GS1 DataBar CC-A/GS1 DataBar Stacked/GS1 DataBar Stacked CC-A/GS1 DataBar Limited/ GS1 DataBar Limited CC-A/GS1 DataBar Truncated/GS1 DataBar Truncated CC‐A
	Logo image	Custom character font and logo (CAD) data, BMP/JPEG/PNG/TIFF
Marking conditions	Workpiece style	Stationary marking, Moving marking (constant, encoder)
	Character size (marking height/width)	0.1 to 330 mm
	No. of registered programs	2,000 max.
	No. of program blocks	256
I/O (Input/output)		Terminal block I/O, MIL connector I/O, contactor control I/O^*3
Interface		RS-232C, USB 2.0, Ethernet (100BASE-TX/10BASE-T)^*4
Head installation direction		All directions
Head cable length		4.3 ±0.1 m
Cooling method		Forced air cooling
Rated voltage and power consumption		100 to 120/200 to 240 VAC ±10 %, 50/60 Hz, 650 VA max.
Environmental resistance	Enclosure rating	IP64 (marking head)
	Pollution degree	2
	Overvoltage category	II
	Ambient temperature for storage	-10 to +60 °C (No freezing)
	Ambient temperature	0 to +40 °C
	Ambient humidity for storage Spider man pc game download.	30 to 85 % RH (No condensation)
	Relative humidity
Weight		Controller: 23.0 kg Head: 13.6 kg Console: 2.0 kg
^1 The laser classification for FDA (CDRH) is implemented based on IEC60825-1 in accordance with the requirements of Laser Notice No.50. ^2 The only TrueType and OpenType fonts supported are those fonts whose 'Font embeddability' property is set to 'Installable' or 'Editable.' This property can be viewed from the Properties dialog boxes of the fonts shown on the [Fonts] screen in [Control Panel]. ^3 Supported models: MD-X1000C, MD-X1020C, MD-X1500C, MD-X1520C ^4 There are two USB ports: a Type A connector for connecting USB memory devices or a USB mouse and a Type B connector that is the dedicated port for Marking Builder 3 (ActiveX). The Ethernet port supports communication with Marking Builder 3 (ActiveX), TCP/IP communication, EtherNet/IP^TM, and PROFINET.

Keyence Marking Builder 3 Manual

Model		MD-F3200	MD-F3220	MD-F5200	MD-F5220
Type		Marking unit (Controller + Head) 30 W, Standard area	Marking unit (Controller + Head) 30 W, Wide area	Marking unit (Controller + Head) 50 W, Standard area	Marking unit (Controller + Head) 50 W, Wide area
Console (sold separately)		MC-P1
Marking method		XYZ 3-axis simultaneous scanning method
Marking laser	Type	Yb: Fibre laser (Class 4 laser product; IEC/EN60825-1, JIS C6802, FDA (CDRH) Part 1040.10^*1 , GB7247.1)
	Wavelength	1090 nm
	Output	30 W		50 W
Applicable regulations		EU directive (EMC directive, machinery directive, RoHS directive), EN standard (EN 55011, EN ISO 11553-1, EN 60204-1, EN 60825-1, EN 61000-6-2, EN 50581), CSA and UL standards (CAN/CSA C22.2 No. 61010-1-12, UL 61010-1), North America regulations (FCC Part 15B, ICES-001 Class A), China RoHS
Pulse frequency		60 to 120 kHz
Guide laser/Working distance pointer		Semiconductor laser, Wavelength: 655 nm, Output: 1.0 mW (Class 2 laser product; IEC/EN60825-1, JIS C6802, FDA (CDRH) Part 1040.10^*1 , GB7247.1)
Marking area		125 × 125 × 42 mm	300 × 300 × 42 mm	125 × 125 × 42 mm	300 × 300 × 42 mm
Standard working distance (±variable width)		168 mm (±21 mm)	300 mm (±21 mm)	168 mm (±21 mm)	300 mm (±21 mm)
Marking resolution		2 µm	5 µm	2 µm	5 µm
Scan speed		Max. 12000 mm/s	Max. 8000 mm/s	Max. 12000 mm/s	Max. 8000 mm/s
Character type	Font	KEYENCE original font (numbers, letters, katakana, hiragana, kanji), User fonts, True Type fonts
	Barcode	CODE39, ITF, 2of5, NW7 (CODABAR), JAN, CODE128, EAN, UPC-A, UPC-E, CODE93
	2D code	QR code, Micro QR code/DataMatrix (ECC200/GS1 DataMatrix)
	GS1 DataBar	GS1 DataBar, GS1 DataBar CC-A, GS1 DataBar Stacked, GS1 DataBar Stacked CC-A, GS1 DataBar Limited, GS1 DataBar Limited CC-A, GS1 DataBar Truncated, GS1 DataBar Truncated CC-A
	Logo image	Custom character font and logo CAD data, BMP/JPEG/PNG/TIFF
Marking conditions	Workpiece style	Stationary/moving marking (constant speed/encoder)
	Character size (marking height/width)	0.1 to 125 mm	0.1 to 300 mm	0.1 to 125 mm	0.1 to 300 mm
	No. of registered programs	Max. 2000 programs
	No. of program blocks	256 blocks
I/O (Input/output)		Terminal block I/O, MIL connector I/O
Interface		RS-232C, USB 2.0, Ethernet (100BASE-TX/10BASE-T)^*2
Head installation direction		All directions
Head cable length		4.0 m
Cooling method		Controller: Forced air cooling, Head: Natural air cooling
Rated voltage and power consumption		100 to 120 VAC or 200 to 240 VAC ± 10 %, 50/60 Hz, Max. 550 VA		Single-phase 100 to 120/200 to 240 VAC ±10 %, 50/60 Hz, Max. 750 VA
Environmental resistance	Enclosure rating	IP64 (Head)
	Pollution degree	2
	Overvoltage category	II
	Ambient temperature for storage	-10 to +60 °C (No freezing)
	Ambient temperature	0 to +40 °C
	Ambient humidity for storage	30 to 85 % RH (No condensation)
	Relative humidity
Weight		Controller: 24.0 kg Head: 6.7 kg Console: 2.0 kg		Controller: 25.0 kg Head: 6.7 kg Console: 2.0 kg
^1 The laser classification for FDA (CDRH) is implemented based on IEC60825-1 in accordance with the requirements of Laser Notice No. 50. ^2 The USB port is designed for use with USB memory sticks, barcode readers, mouses (A connector), and Marking Builder 3 (ActiveX) (B connector). The Ethernet port supports communication with Marking Builder 3 (ActiveX), TCP/IP communication, PROFINET connection, and EtherNet/IP^TM connection.
